High Tenacity Polyolefin & Polyester Mixed
Structure: 12-strand
Applications:
Mooring Lines
Anti Snap Back
The Anti Snap Back design is a revolutionary and safe solution for mooring applications, the 12 strand construction rope is easy for handling during operation. This design reduces dangerous snap backs technically and increases the safety of the crew.
| Code | Dia | Circ. | Weight | Unspliced MBL | LDBF, Spliced MBL | ||||
| mm | inch | inch | kg/100m | lbs/100ft | ton | kN | ton | kN | |
| 6103522 | 40 | 1-5/8 | 5 | 90.5 | 60.8 | 36.5 | 357 | 32.8 | 321 |
| 6103523 | 44 | 1-3/4 | 5-1/2 | 109.5 | 73.5 | 43.7 | 428 | 39.3 | 385 |
| 6103525 | 48 | 2 | 6 | 129.4 | 86.9 | 51.6 | 506 | 46.6 | 456 |
| 6103526 | 52 | 2-1/8 | 6-1/2 | 153.9 | 103.3 | 60.1 | 589 | 54.2 | 531 |
| 6103527 | 56 | 2-1/4 | 7 | 177.2 | 119.0 | 69.4 | 680 | 62.4 | 612 |
| 6103528 | 60 | 2-1/2 | 7-1/2 | 204.1 | 137.0 | 79.1 | 776 | 71.3 | 698 |
| 6103530 | 64 | 2-5/8 | 8 | 232.0 | 155.8 | 89.5 | 878 | 80.6 | 790 |
| 6103531 | 68 | 2-3/4 | 8-1/2 | 262.4 | 176.2 | 100.3 | 983 | 90.3 | 885 |
| 6103533 | 72 | 3 | 9 | 293.8 | 197.2 | 111.9 | 1097 | 100.8 | 988 |
| 6103536 | 80 | 3-1/4 | 10 | 362.6 | 243.4 | 136.6 | 1339 | 123.0 | 1205 |
| 6103538 | 88 | 3-5/8 | 11 | 437.3 | 293.6 | 164.6 | 1613 | 147.6 | 1446 |
| 6103540 | 96 | 4 | 12 | 521.2 | 349.9 | 194.4 | 1906 | 174.6 | 1711 |
| 6103542 | 104 | 4-1/4 | 13 | 613.3 | 411.7 | 225.7 | 2211 | 203.0 | 1989 |
| 6103545 | 112 | 4-5/8 | 14 | 705.4 | 473.6 | 261.1 | 2559 | 235.5 | 2308 |
| 6103548 | 120 | 5 | 15 | 813.9 | 546.4 | 298.0 | 2920 | 268.2 | 2629 |
a. Bespoke diameter and length is available.
b. ±5% tolerance according to ISO 2307:2010.
c. LDBF=Line Design Break Force according to OCIMF Mooring Equipment Guidelines 4(MEG4).
The Anti Snap Back design is a revolutionary and safe solution for mooring applications, the 12 strand construction rope is easy for handling during operation. This design reduces dangerous snap backs technically and increases the safety of the crew.
It's a high performance and best rope used for extreme high temperature working condition.It is fatigue and abrasion resistant, with the ability to absorb dynamic loads for long periods of time. The jacket of this construction can be repaired and replaced to offer longer service lifetime.
Mooring tails provide good elasticity and sudden shock absorption when windy weather or big wave comes, it's a necessary protection for primary mooring line .
This structure is non - rotative and torque free construction, the rope will not kink, round and firm structure makes rope grip well. Also braided Jacket enhance rope with excellent wear resistance and increase the Structure: UHMWPE 12-strand Load-bearing Core & Polyester Braided Jacketservice life of the rope.
HOPEX MIX is crafted from a blend of UHMWPE (Ultra-High Molecular Weight Polyethylene) and High Tenacity Polyester fibers, offering a lightweight yet high-strength solution. This rope provides superior abrasion and cut resistance, coupled with a higher coefficient of friction compared to other high modulus polyethylene ropes. It floats, grips securely on winches or capstans, and demonstrates excellent durability.
Double braid rope is non - rotative and torque free construction, the rope will not kink, round and firm structure makes rope grip well. Also double braid construction is very flexible and enhance rope with high strength and excellent wear resistance.
A polypropylene and polyester mixed mooring rope combines the lightweight and buoyant characteristics of polypropylene with the durability and strength of polyester. This blend results in a rope that is both easy to handle and resistant to abrasion, making it suitable for reliable performance in various marine environments.
Made of high tenacity polyolefin fiber, which is the stronger rope among PP, PE and Polyolefin ropes. Excellent breaking strength and remarkable abrasion resistance.
TOUGH-MIX PRO™ REDUCED RECOIL RISK ROPE
